65M Bionic Cherry Tree Camouflaged Galvanized Steel 5G Wifi Garden Tourist Area Eco-friendly Telecom Communication Tower

Name: 65M Bionic Cherry Tree Camouflaged Galvanized Steel 5G Wifi Garden Tourist Area Eco-friendly Telecom Communication Tower
Brand: Jiayao Co., Ltd.
SKU: Bionic Tree Tower
Price: 50.00 USD
Availability: InStock

All Products

3 Legged Angular Steel Tower
(48)

4 Legged Angular Steel Tower
(61)

3 Legged Tubular Steel Tower
(45)

Monopole Tower
(53)

Guyed Wire Tower
(26)

Guard Tower
(15)

Bionic Tree Tower
(25)

Power Transmission Tower
(18)

I'm Online Chat Now

65M Bionic Cherry Tree Camouflaged Galvanized Steel 5G Wifi Garden Tourist Area Eco-friendly Telecom Communication Tower

Large Image : 65M Bionic Cherry Tree Camouflaged Galvanized Steel 5G Wifi Garden Tourist Area Eco-friendly Telecom Communication Tower

Product Details:

Place of Origin:	China
Brand Name:	Jiayao
Certification:	ISO9001:2008 COC
Model Number:	Bionic Tree Tower

Payment & Shipping Terms:

Minimum Order Quantity:	4 Tons
Price:	US$1600,1-100Tons;US$1000,>=100 Tons
Packaging Details:	Packed In Wooden Boxes Or Bundled With Galvanized Sheets
Delivery Time:	15-20 Days
Payment Terms:	L/C, T/T
Supply Ability:	500-800 tons per month

Contact Now Chat Now

65M Bionic Cherry Tree Camouflaged Galvanized Steel 5G Wifi Garden Tourist Area Eco-friendly Telecom Communication Tower

Description

Standard:	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1	Certification:	ISO9001:2008
Galvanization Standard:	ASTM A123/ ISO 1461	Nuts & Bolts:	Grade 8.8/4.8
Product Name:	Bionic Tree Tower	Height:	1-100M
Wind Speed:	5-48KM/H	Service Life:	10-50 Years
Environmental Impact:	Eco-friendly	Aesthetics:	Natural And Realistic Appearance
Accessories:	Ground Anchor
Highlight:	Bionic tree telecom tower , Galvanized steel 5G tower , Eco-friendly communication tower

JIAYAO CO., LTD.

We specialize in designing and manufacturing customized steel towers for telecom, monitoring, observation, and security applications. Below is the detailed product information:

1.Specifications

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q355B, Q355C,Q355D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153

2.Product Detail

Please Click Here For More Information!!!!!!

3.Packaging & Shipping

4.Cooperation Customers

5.Certifications

6.Our Services

JIAYAO CO., LTD. is a professional telecom tower manufacturer and approved by ISO9001. We are committed to providing customers with the most optimized solutions and the best communication tower. Many products have been exported to USA, Europe and other 55 different counties.
We specialize in designing and manufacturer of angle steel tower, tube steel tower, monopole tower, pine tree tower, guyed tower and guard tower. Our departments include design, R&D, inspection, laboratory, QC, galvanization and steel tower departments. Our raw materials come from famous steel mills in China: HBIS Group, Baowu Steel Group, Shougang Group.

If you need it, we will welcome you 24 hours a day!

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel
	GB/T 700:Q235B, Q235C,Q235D
	ASTM A36
	EN10025: S235JR, S235J0,S235J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510
6. Yield strength (t≤16mm) (Mpa)	355
7. Elongation (%)	20
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)
	27(0°C)---Q235C(S235J0)
	27(-20°C)---Q235D(S235J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153
